| Place of Origin | CHINA |
| Brand Name | suzhou beite Smart Instrument Co., Ltd. |
| Certification | CE ISO |
Description
The smart turbine flow meter is a velocity flow meter used to measure gas flow. It has the advantages of simple structure, light weight, high measurement accuracy, good repeatability, wide measurement range, and convenient installation and maintenance. It is widely used in the measurement of various gases in petroleum, chemical industry, metallurgy, aviation, scientific research and other sectors and industrial fields, such as natural gas, city gas, propane, butane, air, nitrogen and other gases. The instrument has high reliability and good repeatability, and is suitable for industrial measurement and industrial process detection.
The smart turbine flow meter is a velocity flow meter used to measure gas flow. It has the advantages of simple structure, light weight, high measurement accuracy, good repeatability, wide measurement range, and convenient installation and maintenance. It is widely used in the measurement of various gases in petroleum, chemical industry, metallurgy, aviation, scientific research and other sectors and industrial fields, such as natural gas, city gas, propane, butane, air, nitrogen and other gases. The instrument has high reliability and good repeatability, and is suitable for industrial measurement and industrial process detection. The medium density of the intelligent turbine flowmeter changes with temperature and pressure. The temperature and pressure of the test medium must be tracked simultaneously during measurement, and the volume flow rate under different working conditions must be converted into a standard state or agreed state, volume flow rate.
Specification
| Specifications and models | DN(mm) |
Flow range (m3/h |
Maximum pressure loss (kPa) |
Start flow (m3/h) |
Pressure Level (Mpa) |
LWQ-25 |
25 | 2～20 | 0.6 | 1 | 1.6 |
| 4～40 | 0.7 | 2 | |||
| LWQ-40 | 40 | 3～50 | 0.7 | 1.8 | |
LWQ-50 |
50 | 5~100 | 0.7 | 2.5 |
|
| 10～150 | 0.7 | ||||
| LWQ-80 | 80 | 10~240 | 0.3 | 6 |
|
| 20～480 | 0.8 | ||||
| LWQ-100 | 100 | 12~360 | 0.2 | 8 |
1.6 |
| 20～600 | 0.5 | ||||
LWQ-150 |
150 | 25～1000 | 0.4 | 15 |
|
| 40～1500 | 1.7 | ||||
LWQ-200 |
200 | 50~2000 | 0.2 | 35 |
|
| 75～2500 | 0.9 | ||||
| LWQ-250 | 250 | 80～3500 | 0.2 | 40 | |
LWQ-300 |
300 |
160～4000 | 0.5 | 50 |
|
| 300～6500 | 1.5 |
Features
1. GOOD PRECISION
The flow meter is a thrust type with carbide bearings, which has good accuracy and improved wear resistance.
2. COMPACT STRUCTURE
Compact and lightweight structure, easy to install and maintain
3. SIMPLE STRUCTURE
Features three: simple structure, solid structure and easy disassembly and assembly
4. HIGH ACCURACY
High accuracy, generally up to ±0.5%R, ±1.0%R, good repeatability
5. REPEATABILITY
Up to 0.05% - 0.2%5
6. PRESSURE RATING
High pressure level, small pressure loss, strong flow capacity and strong vibration resistance
Packing & Delivery
FAQ
1. Q: What information need to be provided to choose the suitable model?
A: Application field, Nominal pressure ,Medium & medium temperture , Power supply , Output,
Flow range, Accuracy, Connection and other parameters.
2. Q: Are you a trade company or a manufacturer?
A: We are an ISO approved manufacturer specialized in level and flow measuring instruments.
OEM & ODM service are available. Welcome to visit us in China.
3. Q: What is your MOQ?
A: To start our cooperation, sample order is acceptable.
4. Q: What is your delivery date for the Intelligent Mini Micro Turbine Fuel Oil Diesel Flow Meter?
A: The delivery date is about 3-15 working days after receipt of payment.
5. Q: What is your payment terms?
A: We support T/T, PayPal ,Western Union.
For mass production order, it is 30% deposit in advance and 70% balance before shipment.
6. Q: Do you have a warranty for the Flow Meter?
A: Yes, we have the warranty of 12 months.
